TRANSCEND Internal Solid State Drive

MTE652T PCIe M.2 SSD 128GB

• Compliant with RoHS 2.0 standards
• Compliant with NVM Express specification 1.3
• Compliant with PCI Express specification 3.1
• Space-saving M.2 form factor (80mm) – ideal for mobile computing devices
• PCIe Gen 3 x4 interface
• DDR3 DRAM Cache embedded
• Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
• Key components fortified by default with Corner Bond technology
• Anti-sulfur technology implemented to prevent sulfurization in the environment
• Power Shield (PS) to ensure data transfer integrity and minimize data corruption in the drive during an abnormal power outage
• Promised operational reliability in a wide temperature range (from -40°C to 85°C)
• Supports Transcend Scope Pro software

• Dimensions 80 mm x 22 mm x 3.58 mm (3.15" x 0.87" x 0.14")
• Weight 9 g (0.32 oz)
• M.2 Type 2280-D2-M (Double-sided)
• Form Factor M.2 2280

• Bus Interface NVMe PCIe Gen3 x4

• Capacity 128 GB
• Flash Type 3D NAND flash

• Operating Voltage 3.3V±5%
• Operating Temperature Standard Temp.0°C (32°F) ~ 70°C (158°F) Wide Temp.-40°C (-40°F) ~ 85°C (185°F)
• Storage Temperature -55°C (-67°F) ~ 85°C (185°F)
• Humidity 5% ~ 95%
• Shock 1500 G, 0.5 ms, 3 axis
• Vibration (Operating) 20 G (peak-to-peak), 7 Hz ~ 2000 Hz (frequency)

• Power Consumption (Operation) 3.0 watt(s)
• Power Consumption (IDLE) 0.6 watt(s)

• Sequential Read/Write (CrystalDiskMark) Read: Up to 2,100 MB/s, Write: Up to 1,250 MB/s
• 4K Random Read/Write (IOmeter) Read: Up to 190,000 IOPS, Write: Up to 290,000 IOPS
• Mean Time Between Failures (MTBF) 3,000,000 hour(s)
• Terabytes Written (TBW) 270 TBW
• Drive Writes Per Day (DWPD) 2 (3 yrs)

• Certificate CE/FCC/BSMI
• Warranty Three-year Limited Warranty
