TRANSCEND 256GB M.2 2242 SSD SATA3 TLC wide temp
|
|
TRANSCEND 256GB M.2 2242 SSD SATA3 TLC wide temp
Tuotekoodi:
TS256GMTS570T-I
-
Lukunopeus
560MB/s
-
Kirjoitusnopeus
520MB/s
-
Liitäntä
Serial ATA III
-
Form Factor
M.2
-
Kapasiteetti
256GB
|
SATA III M.2 SSD MTS570T-I
TS256GMTS570T-I
Transcend's M.2 SSD MTS570T features the SATA III 6Gb/s interface and the state-of-the-art 3D NAND technology, which allows 112 layers of 3D NAND flash chips to be vertically stacked. Compared to 3D NAND at 96 layers, this density breakthrough greatly improves storage efficiency, and its built-in DRAM cache allows faster access. Applied with 30µ" gold finger PCB and Corner Bond technology, the MTS570T is fully tested in-house to guarantee reliability in mission-critical applications, boasting an endurance rating of 3K Program/Erase cycles and an extended operating temperature ranging from -20℃~75℃.
Transcend also offers the MTS570T-I with wide temperature (-40℃ ~ 85℃) capabilities to ensure sustained functionality, enhanced endurance and optimal reliability in mission-critical applications.
Specifications:
Appearance
- Dimensions 42.0 mm x 22.0 mm x 3.58 mm (1.65" x 0.87" x 0.14")
- Weight 5 g (0.18 oz)
- M.2 Type 2242-D2-B-M (Double-sided)
- Form Factor M.2 2242
Interface
- Bus Interface SATA III 6Gb/s
Storage
- Capacity 128 GB/256 GB/512 GB/1 TB
- Flash Type 112-layer 3D NAND flash
Operating Environment
- Operating Voltage 3.3V±5%
- Operating Temperature
- Extended Temp.-20°C (-4°F) ~ 75°C (167°F)
- Wide Temp.-40°C (-40°F) ~ 85°C (185°F)
- Storage Temperature -55°C (-67°F) ~ 85°C (185°F)
- Humidity 5% ~ 95%
- Shock 15 G, 11 ms, 3 axis
- Vibration (Operating) 20 G (peak-to-peak), 7 Hz ~ 2,000 Hz (frequency)
Power
- Power Consumption (Operation) 4.5 watt(s)
- Power Consumption (IDLE) 1.1 watt(s)
Performance
- Sequential Read/Write (CrystalDiskMark)
- Read: Up to 560 MB/s
- Write: Up to 520 MB/s
- 4K Random Read/Write (IOmeter)
- Read: Up to 90,000 IOPS
- Write: Up to 85,000 IOPS
- Mean Time Between Failures (MTBF) 3,000,000 hour(s)
- Terabytes Written (TBW) Up to 2420 TBW
- Drive Writes Per Day (DWPD) 2.16 (3 yrs)
