| Type | IP security camera |
| Placement supported | Indoor |
| Connectivity technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Infrared (IR) cut-off filter | Yes |
| Certification | CE, CE LVD, FCC, RCM |
| Mounting type | Ceiling |
| Product colour | Black, White |
| Minimum illumination | 0.01 lx |
| Lens viewing angle, horizontal | 180° |
| Lens viewing angle, vertical | 180° |
| Lens viewing angle, diagonal | 180° |
| White balance | Auto |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/12 ~ 1/27000 s |
| Adjustment shutter speed | Auto |
| Sensor type | CMOS |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
| Progressive scan | Yes |
| Number of lenses | 1 |
| Detect distance | 0.5 m |
| Maximum aperture number | 2 |
| Fixed focal length | 1.37 mm |
| Night vision | Yes |
| Night vision distance | 5 m |
| LED type | IR |
| Maximum resolution | 2560 x 1920 pixels |
| Total megapixels | 5 MP |
| Video compression formats | H.264, H.265, M-JPEG |
| Supported graphics resolutions | 640 x 360, 640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2560 x 1440, 2560 x 1920 |
| Supported video modes | 360p, 480p, 720p, 960p, 1080p, 1440p |
| Frame rate | 30 fps |
| Gain control type | Auto |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Time stamp overlay | Yes |
| Text caption overlay | Yes |
| Audio formats supported | LC-AAC |
| Audio codecs | G.711 |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3af |
| Supported network protocols | IPv6, IPv4, ARP, TCP/IP, UDP, ICMP, DHCP client, NTP client (D-Link), DNS client, FTP client, SMTP client, Bonjour, 802.1x, HTTP/HTTPS, PPPoE, UPnP port forwarding, RTP/RTSP/RTCP, CoS, QoS/DSCP, SNMP v1/v2/v3, ONVIF |
| Quality of Service (QoS) support | Yes |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Maximum memory card size | 256 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Password protection | Yes |
| Video motion detection | Yes |
| Active tampering alarm | Yes |
| IP address filtering | Yes |
| Security algorithms | 802.1x RADIUS, HTTPS, SNMP, SNMPv3 |
| Alert notification type | E-mail, Snapshot alert message |
| Web-based management | Yes |
| Web browser | Yes |
| Power source type | AC, DC, PoE |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (Power over Ethernet (PoE)) | 8 W |
| DC output voltage | 12 |
| DC output current | 1.5 A |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
| Height | 29.6 mm |
| Diameter | 10.1 cm |
| Weight | 190 g |
| Package width | 137 mm |
| Package depth | 208 mm |
| Package height | 95 mm |
| Package weight | 690 g |
| Number of cameras | 1 |
| Shipping (inner) case length | 50.2 cm |
| Shipping (inner) case width | 29.7 cm |
| Shipping (inner) case height | 25 cm |
| Shipping (inner) case net weight | 6.9 kg |
| Pallet gross weight (air) | 320 kg |
| Master (outer) cases per pallet (air) | 40 pc(s) |
| Products per pallet (air) | 400 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 138.5 cm |
| Pallet gross weight (sea) | 440 kg |
| Master (outer) cases per pallet (sea) | 56 pc(s) |
| Products per pallet (sea) | 560 pc(s) |
| Pallet height (sea) | 188.5 cm |
| Shipping (inner) case gross weight | 7.5 kg |
| Products per shipping (inner) case | 10 pc(s) |
