HP Pentium G5420T 2C 3 SPS CPU INT CFL R (L69409-003)

Pentium® Gold G5420T

• Product Collection : Intel® Pentium® Gold Processor Series
• Code Name : Products formerly Coffee Lake
• Vertical Segment : Desktop
• Processor Number : G5420T
• Lithography : 14 nm

• # of Cores : 2
• # of Threads : 4
• Processor Base Frequency : 3.20 GHz
• Cache : 4 MB Intel® Smart Cache
• Bus Speed : 8 GT/s
• TDP : 35 W
• Configurable TDP-down Frequency : 2.10 GHz
• Configurable TDP-down : 25 W

• Max Memory Size (dependent on memory type) : 64 GB
• Memory Types : DDR4-2400
• Max # of Memory Channels : 2
• Max Memory Bandwidth : 37.5 GB/s
• ECC Memory Supported : Yes

• Processor Graphics : Intel® UHD Graphics 610
• Graphics Base Frequency : 350 MHz
• Graphics Max Dynamic Frequency : 1.05 GHz
• Graphics Video Max Memory : 64 GB
• 4K Support : Yes, at 60Hz
• Max Resolution (HDMI 1.4) : 4096x2304@24Hz
• Max Resolution (DP) : 4096x2304@60Hz
• Max Resolution (eDP - Integrated Flat Panel) : 4096x2304@60Hz
• DirectX Support : 12
• OpenGL Support : 4.5
• Intel® Quick Sync Video : Yes
• Intel® InTru™ 3D Technology : Yes
• Intel® Clear Video HD Technology : Yes
• Intel® Clear Video Technology : Yes
• # of Displays Supported : 3
• Device ID : 0x3E90/x93

• Scalability : 1S Only
• PCI Express Revision : 3.0
• PCI Express Configurations : Up to 1x16, 2x8, 1x8+2x4
• Max # of PCI Express Lanes : 16

• Sockets Supported : FCLGA1151
• Max CPU Configuration : 1
• Thermal Solution Specification : PCG 2015A (35W)
• TJUNCTION : 88°C
• Package Size : 37.5mm x 37.5mm

• Intel® Optane™ Memory Supported : Yes
• Intel® Turbo Boost Technology : No
• Intel® vPro™ Platform Eligibility : No
• Intel® Hyper-Threading Technology : Yes
• Intel® Virtualization Technology (VT-x) : Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
• Intel® VT-x with Extended Page Tables (EPT) : Yes
• Intel® Transactional Synchronization Extensions : No
• Intel® 64 : Yes
• Instruction Set : 64-bit
• Instruction Set Extensions : Intel® SSE4.1, Intel® SSE4.2
• Idle States : Yes
• Enhanced Intel SpeedStep® Technology : Yes
• Thermal Monitoring Technologies : Yes
• Intel® Identity Protection Technology : Yes
• Intel® Stable Image Platform Program (SIPP) : No

• Intel® AES New Instructions : Yes
• Secure Key : Yes
• Intel® Software Guard Extensions (Intel® SGX) : Yes with Intel® ME
• Intel® Memory Protection Extensions (Intel® MPX) : Yes
• Intel® OS Guard : Yes
• Intel® Trusted Execution Technology : No
• Execute Disable Bit : Yes
• Intel® Boot Guard : Yes
